Airframe:

402 Hours Since New; 151 Landings as of 14 June 2011
Entry to Service Date – October 2010
JAR-OPS1 Compliant
Enrolled on FalconCare

Engines:

Description	Three (3) Pratt & Whitney Canada PW307A
Total Time Since New	402 Hrs	402 Hrs	402 Hrs
Total Cycles Since New	151 Cycles	151 Cycles	151 Cycles
Program Coverage	TBD

APU:

Description	Honeywell GCTP36-150 (FN)
Total Time Since New	443
Program Coverage	TBD

Avionics:

The Falcon 7X benefits from the intuitive EASy flight-deck technology developed for the Falcon aircraft and incorporated into the Falcon 900 and Falcon 2000 series. The system displays information on four 14.1-inch, flat-panel LCD screens arranged in a T-shape. It allows pilots to make “heads up” data entry using a Cursor Control Device (CCD) and menu-driven selections. The Cursor Control Device developed by Dassault Aviation for EASy gives an unprecedented ease of use for the pilots, in all situations. The Falcon 7X is the first business jet with a Digital Flight Control System; conferring a range of benefits, such as precise flight path control, automatic trim adjustments during configuration changes, and basic autopilot functions through the cockpit’s side-stick controller for setting heading and attitude.

Head-Up Guidance System HGS-5860 (CAT I)
Enhanced Flight Vision System CMC-2600 Suresight
Triple VHF Comm TR-886B
Dual HF Comm KHF-1050
Honeywell SELCAL
Triple Audio Panel AV-900
406 ELT w/Nav Interface
Electronic Jeppesen Charts
Primus 880 Weather Radar
TCAS 3000
Attitude Heading Reference System

Triple Flight MGMT Systems
Triple LASEREF IRS
Dual VOR/ILS/MKR/GPS NV-875X
Dual ADF DF-855
Dual DME DM-855
Dual Radar Altimeter KRA-405B
Communications MGMT Function (CMF)
Flight Data Recorder
Standby Instruments
EGPWS
Goodrich Ice Detector

Additional Equipment:

Additional Handsets
Brother Fax/Copier/Printer/ Scanner
Flightdeck Printer
Securaplane Camera System
Airshow 4000
Two (2) 21.3” LCD Monitor
Dual DVD Player
Teleflex Tail Recognition Light System
Mechanical A-Type Entertainment Controls
Additional Auxiliary Audio/Video Interface for Portable Devices
KGS Electronics Static Inverter

Satcom Aero H+ / Swift 64 Thrane and Thrane AERo HSD+
High Speed Data Unit (with Provisions for TT-5040A Swift Broadband HSU)
Autothrottle
Collins Entertainment and Environmental Control System
2 Collins Color OLED Touch-Screen Entertainment Controls
Three (3)Plug-in LCD Monitor Receptacles
Two(2) Plug-in 10.4” LCD Monitor

Interior Configuration:

Fifteen (15) passenger configuration featuring a forward four (4) place double club, mid cabin four (4) place dining group opposite of a two (2) place club, and aft two (2) place club opposite of a three (3) place divan. This aircraft has a forward crew lavatory and a large aft lavatory. The full service galley is located in the forward cabin.

Weights:

Max Ramp Weight – 69,200 lbs	Max Zero Fuel Weight – 41,000 lbs
Max Takeoff Weight – 69,000 lbs	Basic Empty Weight – 35,559 lbs
Max Landing Weight – 62,400 lbs	Fuel Capacity (Usable) – 31,940 lbs

Warranty:

The Dassault Falcon Jet 10-year airframe warranty is one of the most comprehensive on any certified aircraft in the industry and is generally outlined as follows:

Major Airframe                                                      10 years / 10,000 Hours
Components Manufactured
by Company or Vendors                                      5 Years / 5,000 Hours
Paint / Interior                                                        2 Years / 2,000 Hours
Labor for Paint / Interior                                        2 Years / 2,000 Hours
Labor for Components
Removal & Re-Installation                                     5 Years / 5,000 Hours
Engines                                                                 5 Years / 3,000 Hours
APU                                                                       5 Years / 3,000 Hours
